Usage Examples
Practical examples of how to use the Frame3D API for various use cases.
Single Render
Generate a single image from a specific angle.
curl -X POST https://api.frame3d.dev/single \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"roll": 15,
"pitch": 15,
"yaw": 45,
"outputFormat": "png"
}'
Single Render Response
{
"success": true,
}
Single Render Result
Single Render with Metadata
Generate an image and retrieve model metadata in the same request.
curl -X POST https://api.frame3d.dev/single \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"includeMetadata": true,
"background": "radial-gradient(circle, #5f5f5f 0%, #141414 120%)",
"yaw": 45,
"cameraDistance": 75,
"width": 1200,
"height": 800,
"outputFormat": "png"
}'
Metadata Response
{
"success": true,
"metadata": {
"triangles": 29160,
"vertices": 36951,
"meshes": 1,
"materials": [
"default"
],
"textures": 3,
"fileSize": 22538500,
"isTextured": true,
"animations": [
{
"name": "IdleGround",
"duration": 6.616666793823242,
"channels": 325
},
{
"name": "RiseUp",
"duration": 3.633333444595337,
"channels": 325
},
{
"name": "Roar",
"duration": 6.5,
"channels": 320
},
{
"name": "RoarToWalk",
"duration": 2.866666555404663,
"channels": 325
},
{
"name": "Walk",
"duration": 2.4833333492279053,
"channels": 319
},
{
"name": "Fall",
"duration": 5.733333110809326,
"channels": 327
}
]
}
}
Metadata Result
Batch Render
Generate multiple images with different parameters in a single request.
curl -X POST https://api.frame3d.dev/batch \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"includeMetadata": true,
"frames": [
{
"width": 1024,
"height": 1024,
"roll": 0,
"pitch": 0,
"yaw": 0,
"background": "radial-gradient(circle, #ffffff 0%, #2b2b2b 150%)",
"outputFormat": "png"
},
{
"width": 1024,
"height": 1024,
"roll": 0,
"pitch": 0,
"yaw": 90,
"background": "radial-gradient(circle, #ffffff 0%, #2b2b2b 150%)",
"outputFormat": "png"
},
{
"width": 1024,
"height": 1024,
"roll": 0,
"pitch": 90,
"yaw": 0,
"background": "radial-gradient(circle, #ffffff 0%, #2b2b2b 150%)",
"outputFormat": "png"
}
]
}'
Batch Result
Rotation Sequence
Generate a sequence of frames rotating around the model.
curl -X POST https://api.frame3d.dev/sequence \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"rotationAxis": "y",
"frameCount": 32,
"width": 1200,
"height": 800,
"background": "radial-gradient(circle, #5f5f5f 0%, #141414 120%)",
"outputFormat": "png"
}'
Rotation Result
Dynamic Orbit
Create a dynamic camera movement sequence.
curl -X POST https://api.frame3d.dev/sequence \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"frameCount": 32,
"width": 1200,
"height": 800,
"cameraOrbitSwingY": 65,
"rotationOrbit": "x",
"skybox": "https://example.com/space.jpg",
"outputFormat": "png"
}'
Dynamic Orbit Result
Animation Sequence
Render a sequence of a specific animation from the model.
curl -X POST https://api.frame3d.dev/sequence \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"frameCount": 32,
"background": "radial-gradient(circle, #5f5f5f 0%, #141414 120%)",
"yaw": 45,
"cameraDistance": 75,
"width": 1200,
"height": 800,
"animationName": "Armature|Walk",
"outputFormat": "png"
}'
Animation Result
Video Generation with FFmpeg
You can combine the generated frames into a video file using FFmpeg.
Note:
The hosted API limits frameCount to 32 per request. To generate longer sequences (like the 66 frames below), you would need to make multiple requests or run Frame3D locally.
FFmpeg: Generate Frames
curl -X POST https://api.frame3d.dev/sequence \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"background": "radial-gradient(circle, #5f5f5f 0%, #141414 120%)",
"frameCount": 66,
"rotationAxis": "y",
"width": 1280,
"height": 720,
"shadowIntensity": 0.5,
"shadowSoftness": 0.5,
"outputFormat": "png"
}'
FFmpeg: Convert to WebM
For a 3-second video (approx 23 fps):
ffmpeg -framerate 23 -i frame-%d.png -c:v libvpx-vp9 -crf 34 -b:v 0 -pix_fmt yuv420p -g 128 -an animation.webm
FFmpeg Result
Interactive Turntable
Create an interactive 360° view of your model.
Generate Frames
curl -X POST https://api.frame3d.dev/sequence \
-H "Content-Type: application/json" \
-H "x-api-key: YOUR_API_KEY" \
-d '{
"model": "https://example.com/model.glb",
"rotationAxis": "y",
"frameCount": 16,
"yaw": 315,
"width": 1536,
"height": 1536,
"outputFormat": "png"
}'
Turntable Preview
Hover + move to rotate
Frame 00
React Turntable Component
import { useEffect, useRef, useState } from "react"
export function Turntable({
frames,
alt = "Turntable frame",
width = 800,
height = 600,
className = "",
}) {
const [frameIndex, setFrameIndex] = useState(0)
const lastXRef = useRef(null)
const deltaRef = useRef(0)
useEffect(() => {
if (frames.length <= 1) return
const preloaded = []
frames.slice(1).forEach((src) => {
const img = new window.Image()
img.src = src
preloaded.push(img)
})
return () => {
preloaded.forEach((img) => {
img.onload = null
})
}
}, [frames])
const framesCount = frames.length
const currentFrame = frames[frameIndex] ?? frames[0]
const stepFrame = (delta) => {
if (!framesCount) return
setFrameIndex((prev) => {
const next = (prev + delta) % framesCount
return next < 0 ? next + framesCount : next
})
}
const handleMouseEnter = (event) => {
lastXRef.current = event.clientX
deltaRef.current = 0
}
const handleMouseLeave = () => {
lastXRef.current = null
deltaRef.current = 0
}
const handleMouseMove = (event) => {
if (lastXRef.current === null || !framesCount) return
const dx = event.clientX - lastXRef.current
lastXRef.current = event.clientX
deltaRef.current += dx
const threshold = 25
if (deltaRef.current >= threshold) {
const steps = Math.floor(deltaRef.current / threshold)
deltaRef.current -= steps * threshold
stepFrame(steps)
} else if (deltaRef.current <= -threshold) {
const steps = Math.floor(deltaRef.current / threshold)
deltaRef.current -= steps * threshold
stepFrame(steps)
}
}
return (
<div
className={`relative flex flex-col items-center select-none ${className}`}
onMouseEnter={handleMouseEnter}
onMouseLeave={handleMouseLeave}
onMouseMove={handleMouseMove}
>
<div className="relative w-full overflow-hidden">
{currentFrame ? (
<img
src={currentFrame}
alt={alt}
width={width}
height={height}
className="mx-auto h-full w-full object-cover"
/>
) : (
<div className="aspect-[4/3] w-full" aria-hidden />
)}
</div>
</div>
)
}
